M8700-C Side Mount Level Switch
Dependable polypropylene float switch with 316 SS stem and high-capacity NC switch, rated to 221 °F/100 PSI.
FDA-grade polypropylene float with 316 SS stem
Robust 60 W SPST switch (NC logic)
Rated 221 °F / 100 PSI with fast 1-day availability
- Buy 10 for $32.30 each and save 5%
- Buy 25 for $30.60 each and save 10%
- Buy 100 for $28.90 each and save 15%
The M8600 Single Point Level Switch combines a rigid 316 stainless-steel stem with a food-safe polypropylene float to deliver reliable level detection in both industrial and food-grade systems. Featuring a 60 W—normally closed—SPST switch, it confidently operates under demanding conditions up to 221 °F and 100 PSI. Fully certified to CE, CSA, UL, and NSF standards and backed by a 1-year warranty, this switch ships quickly and performs dependably. MadisonSensor recommends requesting a quote for precise pricing or specifications and is ready to provide custom solutions tailored to your application needs.
| Sensor Type | Float |
|---|---|
| Orientation | Horizontal |
| Mounting Type & Size | 3/4" NPT |
| Float Material | Polypropylene |
| Stem Material | Polypropylene |
| Switch Logic | Normally Open, Normally Closed |
| Switch Rating | 30 WATT SPST |
| Electrical Ratings | 240V AC, 0.14A; 120V AC, 0.28A; 120V DC, 0.07A; 24V DC, 0.28A |
| Temperature (Max-Celsius) | 105 |
| Temperature (Max-Fahrenheit) | 221 |
| Maximum Pressure (BAR) | 7 |
| Maximum Pressure (PSI) | 100 |
| Minimum Media SG | 0.63 |
| Electrical Termination | 24”, 22 AWG, MTW insulated |
| Float Diameter | 0.6" |
| Slosh Shield | No |
| Approvals | CE, CSA LR56150, cULus E54633, NSF/ANSI/CAN 372 |
| Lead Time | 1 Business Day |
| Warranty | 1 Year |
