M5010 Side Mount Level Switch (Normally Closed)
Compact, horizontal stainless-steel float switch offering dependable normally-closed level detection.
316 SS corrosion-resistant build
Compact side-mount orientation
Reliable normally-closed SPST output
The M5010 Side Mount Level Switch is a robust, stainless-steel float sensor offering precise liquid level detection for horizontal installations in demanding industrial environments. Designed for use in chemical, food processing, and HVAC applications, it ensures consistent performance at temperatures up to 200 °C and pressures up to 300 PSI. Its normally-closed SPST switch logic supports fail-safe control, while CE, CSA, cULus, and NSF approvals reinforce its reliability. MadisonSensor prefers that you request a quote for accurate pricing confirmation and is ready to deliver custom solutions tailored to your needs.
| Sensor Type | Float |
|---|---|
| Orientation | Horizontal |
| Mounting Type & Size | 3/8-24 UNF |
| Float Material | 316 Stainless Steel |
| Stem Material | 316 Stainless Steel |
| Switch Logic | Normally Closed |
| Switch Rating | 30 WATT SPST |
| Electrical Ratings | 240V AC, 0.14A; 120V AC, 0.28A; 120V DC, 0.07A; 24V DC, 0.28A |
| Temperature (Max-Celsius) | 200 |
| Temperature (Max-Fahrenheit) | 392 |
| Maximum Pressure (BAR) | 21 |
| Maximum Pressure (PSI) | 300 |
| Minimum Media SG | 0.91 |
| Electrical Termination | 24”, 22 AWG, Teflon insulated |
| Float Diameter | 1.18" |
| Slosh Shield | No |
| Approvals | CE, CSA LR56150, cULus E54633, NSF/ANSI 169 |
| Lead Time | 1 Business Day |
| Warranty | 1 Year |
