M4546 Tilt Float Single Point Level Switch (6.6' Cable)
Sturdy tilt-float switch delivering dependable, high-current level control.
Tilt action enables compact installation
Durable polypropylene for chemical resistance
High-current SPDT logic for effective control
The M4546 Tilt Float Single Point Level Switch delivers reliable level detection via tilt-action float technology mounted on a rugged 6.6′ PVC cable. With polypropylene housing and SPDT logic rated at 16 A (8 A switching), it excels in applications needing durable, high-current switching at low pressures. Its compact, suspendable design, coupled with CE approval, quick one-day lead time, and one-year warranty, make it a trusted choice for open tank, sump, and pond systems. MadisonSensor prefers quote requests for price or specification verification and provides custom solutions tailored to your operational needs.
| Sensor Type | Float |
|---|---|
| Orientation | Tilt |
| Mounting Type & Size | Suspendable Cable |
| Float Material | Polypropylene |
| Stem Material | Polypropylene |
| Switch Logic | Normally Closed |
| Switch Rating | 16A at 250V AC (8A switching) |
| Electrical Ratings | 240 VAC, 0.40A; 120 VAC, 1.00A; 120 VDC, 0.40A; 24 VDC, 1.00A |
| Temperature (Max-Celsius) | 70 |
| Temperature (Max-Fahrenheit) | 158 |
| Maximum Pressure (BAR) | 1 |
| Maximum Pressure (PSI) | 14.5 |
| Minimum Media SG | 0.90 |
| Electrical Termination | 6.6' PVC jacketed cable |
| Slosh Shield | No |
| Approvals | CE |
| Lead Time | 1 Business Day |
| Warranty | 1 Year |
