M5601-HP-NO High Pressure Float Switch (Normally Open)
High-pressure 316 SS float switch, SPST normally-open logic, 750 PSI capable, quick lead time.
316 SS vertical design for durability
100 W SPST, normally-open switch for control
High-pressure performance up to 750 PSI
- Buy 10 for $94.05 each and save 5%
- Buy 25 for $89.10 each and save 10%
- Buy 100 for $84.15 each and save 15%
The M5601-HP-NO High-Pressure Float Switch is engineered for robust performance in demanding applications. Featuring a 316 stainless-steel float and stem with a normally-open 100 W SPST configuration, it provides dependable level detection at temperatures up to 392 °F and pressures up to 750 PSI. Approved for CE, CSA, cULus, and NSF/ANSI 169 and backed by a 1-year warranty, this vertical switch ensures reliability and compliance. With a 5-business-day lead time, MadisonSensor encourages requesting a quote to verify pricing and specifications, and offers custom solutions tailored to your specific requirements.
| Sensor Type | Float |
|---|---|
| Orientation | Vertical |
| Mounting Type & Size | 1/4" NPT |
| Float Material | 316 Stainless Steel |
| Stem Material | 316 Stainless Steel |
| Switch Logic | Normally Open |
| Switch Rating | 100 WATT SPST |
| Electrical Ratings | 240V AC, 0.40A; 120V AC, 1.0A; 120V DC, 0.40A; 24V DC, 1.0A |
| Temperature (Max-Celsius) | 200 |
| Temperature (Max-Fahrenheit) | 392 |
| Maximum Pressure (BAR) | 52 |
| Maximum Pressure (PSI) | 750 |
| Minimum Media SG | 0.88 |
| Electrical Termination | 24", 22 AWG, Teflon Insulated |
| Float Diameter | 2.05" |
| Slosh Shield | No |
| Approvals | CE, CSA LR56150, cULus E54633, NSF/ANSI 169 |
| Lead Time | 1 Business Day |
| Warranty | 1 Year |
